CIRCUIT BRKR 25A SUR MT

187 - Series Thermal Circuit Breakers - Surface Mount 25 Amp Circuit Breaker PN: 7135 Features: Combines switching and circuit protection into a single device ; All components meet SAE J1171 external ignition protection requirements ; Clear, single lever operation ; "Trip Free" design cannot be held "ON" during fault current condition ; Waterproof ; Recessed mounting holes for clean appearance ; Large clearance around terminal studs accept heavy gauge wire lugs ; Robust 5/16 terminals provide high torque connections ; Large lever with vertical/horizontal orientation provides indication of trip status ; Ignition protected - safe for installation aboard gasoline powered boats; Specifications Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC 3,000 Amperes @24 Volts DC 1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C°.
